The Model SuperFIX VFM™ Skylight is a FM approved high performance translucent system for industrial buildings.

SPECIAL DESIGN

1.

FM Approved Model SuperFIX VFM™ Skylight is a pre-manufactured continuous barrel-vaulted dayli- ght skylight strip system specially designed for industrial applications.

2.

Model SuperFIX VFM™ Skylight is manufactured with Nano-technology that allows the product to achieve the best FM re resistant rates.

3.

All components of Model SuperFIX VFM™ Skylight are pre-manufactured under strict quality standards and controlled environments achieving exceptional results in terms of end product quality and processing times.

4.

Thanks to the Ultra-High Diffusing Nanogel Polycarbonate, Model SuperFIX VFM™ Skylight offers saving in energy consumption. It is proven that an industrial building can operate with its lights turned off throughout the day.

ADVANTAGES

No water leakage at all.

First skylight worldwide FM approved.

Easily adapts to any metallic roofing.

Model SuperFIX VFMTM Skylight is basically maintenance free.

It’s installation is clean and easy.

Due to its microcrystal pigments the Model SuperFIX VFM™ Skylight achieves the best diffusion ligth-transmission in the market.

SIZE AND MEASUREMENTS

The Model SuperFIX VFM™ Skylight is available in 920 mm (36.2in) wide by multiple (unlimited) lengths ranging in modules of 1830 mm (72in).

Lengths continuously attached together as specified. Structural spans are maximum 1520mm (5ft).

APLICATIONS

Continuous Barrel-Vaulted daylight Skylight Strip System for industred complex/ buildings.

QUALITY CONTROL

The Model SuperFIX VFM™ Skylight is manufactured with the highest quality standards, its design and manufacturing process is evaluated by a highly trained quality staff.
